In today’s world of rapid urban development, going underground is just as important as building up. Whether it’s constructing deep basements in crowded city centers, tunneling for metro systems, or protecting structures from groundwater, diaphragm walls play a critical—yet often overlooked—role in ensuring safety, stability, and long-term performance.
Having worked on several underground infrastructure projects, I’ve seen firsthand how diaphragm walls can make or break the success of deep excavation. These aren’t just concrete barriers—they are engineered systems designed with precision to handle extreme earth and water pressures while minimizing risks to nearby buildings and underground utilities.
So, what exactly are diaphragm walls?
They are reinforced concrete walls built directly into the ground using slurry trench technology. This method allows contractors to dig deep trenches—sometimes over 70 meters—without the trench collapsing, thanks to the stabilizing properties of bentonite slurry. Once excavated, a steel cage is inserted, and concrete is poured using the tremie method to form a seamless, watertight, and load-bearing wall.
Their technical reliability – versatility in different soil conditions, and ability to prevent water ingress make diaphragm walls a preferred choice for engineers working on complex, high-stakes projects.

What Are Diaphragm Walls and Why Do They Matter?
A diaphragm wall is a continuous, reinforced concrete wall built into the ground to support deep excavations. Think of it as a vertical underground shield that allows engineers to dig safely while protecting surrounding structures and keeping groundwater at bay.
They’re often used in:
- Dense city centers where space is limited
- Deep basements and underground stations
- Areas with high groundwater levels
- Critical infrastructure like dams and tunnels
Where Diaphragm Walls Make the Biggest Impact
- Commonly used in urban areas to build deep basements without disturbing nearby buildings.
- Essential for constructing metro stations and tunnels safely in busy city environments.
- Provide strong support for deep foundations in high-rise buildings, bridges, and other large structures.
- Act as reliable waterproof barriers to prevent water from entering basements and underground spaces.
- Used to control or block groundwater flow beneath dams or in contaminated areas to protect the structure and environment.
How Diaphragm Walls Are Built – Step-by-Step
1. Guide Wall Setup
Before anything deep happens, small concrete walls are cast at the surface to guide the heavy machinery and mark where the wall will go.
2. Trench Excavation with Slurry
A narrow trench is dug using grabs or hydromills. But here’s the twist—it’s immediately filled with a bentonite slurry (a thick, clay-based liquid) that keeps the trench walls from collapsing and prevents water from rushing in.
3. Steel Reinforcement Cage Placement
Long steel cages, custom-made for the wall’s design, are carefully lowered into the slurry-filled trench. These cages provide the muscle of the diaphragm wall.
4. Tremie Concrete Pouring
Concrete is poured from the bottom up using tremie pipes, which pushes the slurry upwards and locks the concrete in place, panel by panel.
5. Creating a Continuous Wall
Once the initial (primary) panels harden, secondary panels are poured in between. Together, they form a seamless, interlocked wall.
6. Slurry Recovery & Recycling
The displaced slurry is either reused after treatment or disposed of properly—one of many eco-conscious steps in the process.
Key Features of Diaphragm Walls
- Exceptional Strength and Stiffness: Designed to withstand high earth and water pressures, making them suitable for deep excavations.
- Superior Watertightness: The combination of bentonite slurry and interlocking panels ensures minimal water ingress.
- Customizable Dimensions: Can be constructed in a variety of thicknesses (typically 600 mm to 1500 mm) and depths (up to 70 meters or more).
- Low Vibration and Noise: The slurry trench method produces less vibration and noise than traditional piling, protecting nearby structures.
- Versatility: Effective in a wide range of soil conditions, including soft clays and high water tables.

Important Considerations
- Specialized Expertise Required: Construction demands skilled operators and advanced equipment.
- Environmental Management: Proper handling and disposal or recycling of bentonite slurry is essential.
- Cost: Diaphragm walls are generally more expensive than conventional retaining walls, but their performance justifies the investment.
- Quality Control: Continuous monitoring of trench stability, slurry properties, and concrete quality is crucial.
- Construction Timeline: The process can be time-consuming, but the safety and durability benefits are significant.
Recent Innovations and Trends
- Advanced Excavation Tools: Hydromills and digital monitoring systems allow for deeper, more precise trenches.
- Sustainability Focus: Use of biodegradable slurry fluids and improved recycling methods is making diaphragm wall construction more eco-friendly.
- BIM Integration: Building Information Modeling (BIM) streamlines planning and execution, reducing errors and improving coordination.
- Real-Time Monitoring: Sensors and digital systems provide instant feedback on trench stability and wall alignment, enhancing safety and quality.
Additional Considerations in Diaphragm Wall Construction
- Diaphragm wall construction is a complex process requiring specialized equipment and expertise.
- The use of bentonite slurry necessitates proper disposal or recycling after construction.
- While a robust solution, diaphragm walls can be expensive compared to other retaining wall options.
FAQ’s – Frequently Asked Questions
1. What is a diaphragm wall?
A diaphragm wall is a reinforced concrete wall constructed in the ground to support deep excavations and control groundwater. It is commonly used in metro projects, basements, tunnels, and high-rise foundations.
2. Why are diaphragm walls used?
They are used for retaining soil, resisting water pressure, and ensuring structural safety during deep underground construction in dense urban or high groundwater areas.
3. How is a diaphragm wall constructed?
Construction involves:
Guide wall setup
Trench excavation with bentonite slurry
Placement of steel cage
Concrete pouring using the tremie method
Panel interlocking
Slurry recovery
4. What is bentonite slurry and why is it used?
Bentonite slurry is a clay-based fluid used to stabilize trench walls during excavation and prevent collapse or water ingress.
5. What is the depth and thickness of diaphragm walls?
Typically, diaphragm walls are 600 mm to 1500 mm thick and can be built to depths of 20 to 70 meters or more.
6. What are primary and secondary panels?
Primary panels are constructed first and left to set. Secondary panels are placed between them to form a continuous interlocked wall.
7. What are the advantages of diaphragm walls?
High strength and stiffness
Excellent waterproofing
Minimal vibration and noise
Works in various soil conditions
8. What are the disadvantages of diaphragm walls?
High construction cost
Requires skilled labor and equipment
Time-consuming process
Complex slurry management
9. Where are diaphragm walls used?
Underground metro stations
Deep basements in cities
Tunnel approaches
Dams and water-retaining structures
High-rise foundations
How does the tremie method work in diaphragm wall construction?
The tremie method involves pouring concrete through a vertical pipe from the bottom up, displacing slurry and avoiding segregation.
